Toggle switch flashlight
Battery → toggle switch → resistor → LED. Click the lever to flick it — the contact latches, and the position saves with the circuit.
What's on the bench
- Battery
- LED
- Resistor
- Toggle switch
How it's wired
- hole B+5→hole a10
- hole a17→hole B-9
This project runs prebuilt firmware on the emulated board; open it in the simulator to watch it work and inspect every part live.
